For the building shell, the one I'm interested in, it would be not to difficault to do such document because most important dimension (concrete volume) is allready available for arch elemets in freecad.
Having all the defined properties in freecad it would be possible to do a contract document or an estimate of costs for which all dimensions and properties of a building are needed. In my opinion the biggest lack of Allplan, a really huuuuuuuuuge one. One has to group elements to layers and change the visibility of layers. But in Nemetschek Allplan it is not possible to change the visibility of an element according the element properties. One can choose from a cataloge of more than 500 properties and of course define their own properties. In Nemetschek Allplan the property is called attribut.
The whole openstreetmapformat ist done this way. I'm going one step further, there are actually hundreds of properties which could be defined the way Property -> Value. Yea I like the drop-down list property idea. An arch elemet reinforcement would be much more easier than all this cylinders. I could provide every information regarding reinforcement, hopfully It's the buissnis I work in, doing structural calculations and reinforcement drawings. I'm gone open a new thread as soon as the script runs the way I want it to run. Value -> ifcslab, ifcbeam, ifcolumn, ifcwall, ifcallthearchitectureelementswhichmakesabuildinghomelikebutengineersdontcareabout. Such property would be even exact what one needs to distingish between building elements. If freecad will export to ifc one day, it needs such property.
